S88R58減速機詳細信息
S88R58減速機
S88R58減速機電機功率：S88R58Y0.12KW減速機,S88R58Y0.18KW減速機,S88R58Y0.25KW減速機,S88R58Y0.37KW減速機,S88R58Y0.55KW減速機,S88R58Y0.75KW減速機,S88R58Y1.1KW減速機,S88R58Y1.5KW減速機（可配變頻電機，剎車電機，防爆電機，伺服電機，交流電機，直流電機，三相電機，單相電機）。
S88R58減速機配0.12KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| S88R58-Y0.12KW | 6706 | 0.12KW | 0.21r/min | 2690N.m | 123.5kg | 27100N | 0.95 |
| S88R58-Y0.12KW | 5875 | 0.12KW | 0.23r/min | 2400N.m | 123.5kg | 27700N | 1.05 |
| S88R58-Y0.12KW | 5187 | 0.12KW | 0.27r/min | 1980N.m | 123.5kg | 28500N | 1.25 |
| S88R58-Y0.12KW | 4606 | 0.12KW | 0.30r/min | 1760N.m | 123.5kg | 28800N | 1.40 |
| S88R58-Y0.12KW | 3872 | 0.12KW | 0.36r/min | 1460N.m | 123.5kg | 29200N | 1.70 |
S88R58減速機配0.18KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| S88R58-Y0.18KW | 4606 | 0.18KW | 0.29r/min | 3010N.m | 124kg | 19200N | 0.85 |
| S88R58-Y0.18KW | 3872 | 0.18KW | 0.34r/min | 2510N.m | 124kg | 27500N | 1.00 |
| S88R58-Y0.18KW | 3475 | 0.18KW | 0.38r/min | 2420N.m | 124kg | 27700N | 1.05 |
| S88R58-Y0.18KW | 2905 | 0.18KW | 0.45r/min | 2030N.m | 124kg | 28400N | 1.25 |
| S88R58-Y0.18KW | 2586 | 0.18KW | 0.51r/min | 1760N.m | 124kg | 28800N | 1.40 |
| S88R58-Y0.18KW | 2335 | 0.18KW | 0.57r/min | 1570N.m | 124kg | 29100N | 1.60 |
| S88R58-Y0.18KW | 2054 | 0.18KW | 0.64r/min | 1360N.m | 124kg | 29300N | 1.85 |
| S88R58-Y0.18KW | 1824 | 0.18KW | 0.72r/min | 1200N.m | 124kg | 29500N | 2.10 |
| S88R58-Y0.18KW | 1631 | 0.18KW | 0.81r/min | 1080N.m | 124kg | 29600N | 2.30 |
S88R58減速機配0.25KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| S88R58-Y0.25KW | 2905 | 0.25KW | 0.45r/min | 2930N.m | 128kg | 22200N | 0.85 |
| S88R58-Y0.25KW | 2586 | 0.25KW | 0.50r/min | 2560N.m | 128kg | 27400N | 1.00 |
| S88R58-Y0.25KW | 2335 | 0.25KW | 0.56r/min | 2290N.m | 128kg | 27900N | 1.10 |
| S88R58-Y0.25KW | 2054 | 0.25KW | 0.63r/min | 1990N.m | 128kg | 28400N | 1.25 |
| S88R58-Y0.25KW | 1824 | 0.25KW | 0.71r/min | 1770N.m | 128kg | 28800N | 1.40 |
| S88R58-Y0.25KW | 1631 | 0.25KW | 0.80r/min | 1580N.m | 128kg | 29100N | 1.60 |
| S88R58-Y0.25KW | 930 | 0.25KW | 1.40r/min | 930N.m | 128kg | 29700N | 2.70 |
S88R58減速機配0.37KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| S88R58-Y0.37KW | 2054 | 0.37KW | 0.67r/min | 2850N.m | 128.5kg | 24500N | 0.90 |
| S88R58-Y0.37KW | 1824 | 0.37KW | 0.76r/min | 2530N.m | 128.5kg | 27400N | 1.00 |
| S88R58-Y0.37KW | 1631 | 0.37KW | 0.85r/min | 2260N.m | 128.5kg | 28000N | 1.10 |
| S88R58-Y0.37KW | 930 | 0.37KW | 1.50r/min | 1340N.m | 128.5kg | 29400N | 1.85 |
| S88R58-Y0.37KW | 831 | 0.37KW | 1.70r/min | 1210N.m | 128.5kg | 29500N | 2.10 |
S88R58減速機配0.55KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| S88R58-Y0.55KW | 1332 | 0.55KW | 1.00r/min | 2800N.m | 133kg | 25400N | 0.90 |
| S88R58-Y0.55KW | 1191 | 0.55KW | 1.20r/min | 2530N.m | 133kg | 27400N | 1.00 |
| S88R58-Y0.55KW | 1032 | 0.55KW | 1.30r/min | 2200N.m | 133kg | 28100N | 1.15 |
| S88R58-Y0.55KW | 930 | 0.55KW | 1.50r/min | 2030N.m | 133kg | 28400N | 1.25 |
| S88R58-Y0.55KW | 831 | 0.55KW | 1.70r/min | 1840N.m | 133kg | 28700N | 1.35 |
| S88R58-Y0.55KW | 719 | 0.55KW | 1.90r/min | 1600N.m | 133kg | 29000N | 1.55 |
| S88R58-Y0.55KW | 624 | 0.55KW | 2.20r/min | 1390N.m | 133kg | 29300N | 1.80 |
| S88R58-Y0.55KW | 558 | 0.55KW | 2.50r/min | 1260N.m | 133kg | 29400N | 2.00 |
| S88R58-Y0.55KW | 435 | 0.55KW | 3.20r/min | 1010N.m | 133kg | 29700N | 2.40 |
S88R58減速機配0.75KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| S88R58-Y0.75KW | 1032 | 0.75KW | 1.40r/min | 2940N.m | 134kg | 21700N | 0.85 |
| S88R58-Y0.75KW | 930 | 0.75KW | 1.50r/min | 2710N.m | 134kg | 27000N | 0.90 |
| S88R58-Y0.75KW | 831 | 0.75KW | 1.70r/min | 2450N.m | 134kg | 27600N | 1 .00 |
| S88R58-Y0.75KW | 719 | 0.75KW | 2.00r/min | 2130N.m | 134kg | 28200N | 1.15 |
| S88R58-Y0.75KW | 624 | 0.75KW | 2.30r/min | 1860N.m | 134kg | 28700N | 1.35 |
| S88R58-Y0.75KW | 558 | 0.75KW | 2.60r/min | 1680N.m | 134kg | 28900N | 1.50 |
| S88R58-Y0.75KW | 435 | 0.75KW | 3.30r/min | 1340N.m | 134kg | 29300N | 1.80 |
| S88R58-Y0.75KW | 323 | 0.75KW | 4.40r/min | 1030N.m | 134kg | 29700N | 2.30 |
S88R58減速機配1.1KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| S88R58-Y1.1KW | 624 | 1.1KW | 2.30r/min | 2800N.m | 138kg | 25500N | 0.90 |
| S88R58-Y1.1KW | 558 | 1.1KW | 2.60r/min | 2530N.m | 138kg | 27400N | 1.00 |
| S88R58-Y1.1KW | 485 | 1.1KW | 2.90r/min | 2230N.m | 138kg | 28000N | 1.10 |
| S88R58-Y1.1KW | 435 | 1.1KW | 3.30r/min | 2030N.m | 138kg | 28400N | 1.20 |
| S88R58-Y1.1KW | 378 | 1.1KW | 3.80r/min | 1780N.m | 138kg | 28800N | 1.35 |
| S88R58-Y1.1KW | 323 | 1.1KW | 4.40r/min | 1550N.m | 138kg | 29100N | 1.55 |
| S88R58-Y1.1KW | 281 | 1.1KW | 5.00r/min | 1360N.m | 138kg | 29300N | 1.75 |
| S88R58-Y1.1KW | 255 | 1.1KW | 5.60r/min | 1450N.m | 138kg | 29200N | 1.35 |
| S88R58-Y1.1KW | 222 | 1.1KW | 6.40r/min | 1270N.m | 138kg | 29400N | 1.55 |
| S88R58-Y1.1KW | 205 | 1.1KW | 6.90r/min | 1190N.m | 138kg | 29500N | 1.65 |
S88R58減速機配1.5KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| S88R58-Y1.5KW | 485 | 1.5KW | 3.00r/min | 3050N.m | 141kg | 17700N | 0.80 |
| S88R58-Y1.5KW | 435 | 1.5KW | 3.30r/min | 2770N.m | 141kg | 26100N | 0.90 |
| S88R58-Y1.5KW | 378 | 1.5KW | 3.80r/min | 2440N.m | 141kg | 27600N | 1.00 |
| S88R58-Y1.5KW | 323 | 1.5KW | 4.40r/min | 2120N.m | 141kg | 28200N | 1.15 |
| S88R58-Y1.5KW | 281 | 1.5KW | 5.10r/min | 1860N.m | 141kg | 28700N | 1.30 |
| S88R58-Y1.5KW | 255 | 1.5KW | 5.60r/min | 1990N.m | 141kg | 28400N | 1.00 |
| S88R58-Y1.5KW | 222 | 1.5KW | 6.40r/min | 1740N.m | 141kg | 28800N | 1.15 |
| S88R58-Y1.5KW | 205 | 1.5KW | 7.00r/min | 1620N.m | 141kg | 29000N | 1.20 |
S88R58減速器減速比：6706比減速器,5875比蝸輪蝸桿減速機,5187比減速器,4606比減速器,3872比減速器,3475比減速器,2905比減速器,2586比減速器,2335比減速器,2054比減速器,1824比減速器,1631比減速器,1332比減速器,1191比減速器,1032比減速器,930比減速器,831比減速器,719比減速器,624比減速器,558比減速器,485比減速器,435比減速器,378比減速器,323比減速器,281比減速器,255比減速器,222比減速器,205比減速器。
S88R58減速機電機安裝尺寸：輸出軸+鍵Φ64（可定做），高368*寬390（帶輸出軸）*長527
S88R58減速電機輸出轉數：0.21轉減速電機,0.23轉減速電機,0.27轉減速電機,0.29轉自鎖減速機,0.3轉減速電機,0.34轉減速電機,0.36轉減速電機,0.38轉減速電機,0.45轉減速電機,0.5轉減速電機,0.51轉減速電機,0.56轉減速電機,0.57轉減速電機,0.63轉減速電機,0.64轉減速電機,0.67轉減速電機,0.71轉減速電機,0.72轉減速電機,0.76轉減速電機,0.8轉減速電機,0.81轉減速電機,0.85轉減速電機,1轉減速電機,1.2轉減速電機,1.3轉減速電機,1.4轉減速電機,1.5轉減速電機,1.7轉減速電機,1.9轉減速電機,2轉減速電機,2.2轉減速電機,2.3轉減速電機,2.5轉減速電機,2.6轉減速電機,2.9轉減速電機,3轉減速電機,3.2轉減速電機,3.3轉減速電機,3.8轉減速電機,4.4轉減速電機,5轉減速電機,5.1轉減速電機,5.6轉減速電機,6.4轉減速電機,6.9轉減速電機,7轉減速電機。
S88R58減速箱電機輸出扭矩：930N.m減速箱,1010N.m減速箱,1030N.m減速箱,1080N.m減速箱,1190N.m減速箱,1200N.m減速箱,1210N.m減速箱,1260N.m減速箱,1270N.m減速箱,1340N.m減速箱,1360N.m減速箱,1390N.m減速箱,1450N.m減速箱,1460N.m減速箱,1550N.m減速箱,1570N.m減速箱,1580N.m減速箱,1600N.m減速箱,1620N.m減速箱,1680N.m減速箱,1740N.m減速箱,1760N.m減速箱,1770N.m減速箱,1780N.m減速箱,1840N.m減速箱,1860N.m減速箱,1980N.m減速箱,1990N.m減速箱,2030N.m減速箱,2120N.m減速箱,2130N.m減速箱,2200N.m減速箱,2230N.m減速箱,2260N.m減速箱,2290N.m減速箱,2400N.m減速箱,2420N.m減速箱,2440N.m減速箱,2450N.m減速箱,2530N.m減速箱,2560N.m減速箱,2690N.m減速箱,2710N.m減速箱,2770N.m減速箱,2800N.m減速箱,2850N.m減速箱,2930N.m減速箱,2940N.m減速箱,3050N.m減速箱。
S88R58減速機電機各種輸出實物圖：
S88R58減速馬達型號：
SHZ87R57DM63L4,SHZ87R57DM63M4,SHZ87R57DM63MS4,SHZ87R57DM63S4,SHZ87R57DM71D4,SHZ87R57DM71M4,SHZ87R57DM71MS4,SHZ87R57DM71S4,SHZ87R57DM80K4,SHZ87R57DM80M4,SHZ87R57DM80MK4,SHZ87R57DM80N4,SHZ87R57DM80S4,SHZ87R57DM90L4,SHZ87R57DM90M4,SHZ87R57DM90S4,SHZ87R57DR63L4,SHZ87R57DR63M4,SHZ87R57DR63MS4,SHZ87R57DR63S4,SHZ87R57DR71D4,SHZ87R57DR71M4,SHZ87R57DR71MS4,SHZ87R57DR71S4,SHZ87R57DR80K4,SHZ87R57DR80M4,SHZ87R57DR80MK4,SHZ87R57DR80N4,SHZ87R57DR80S4,SHZ87R57DR90L4,SHZ87R57DR90M4,SHZ87R57DR90S4,SHZ87R57DRE63L4,SHZ87R57DRE63M4,SHZ87R57DRE63MS4,SHZ87R57DRE63S4,SHZ87R57DRE71D4,SHZ87R57DRE71M4,SHZ87R57DRE71MS4,SHZ87R57DRE71S4,SHZ87R57DRE80K4,SHZ87R57DRE80M4,SHZ87R57DRE80MK4,SHZ87R57DRE80N4,SHZ87R57DRE80S4,SHZ87R57DRE90L4,SHZ87R57DRE90M4,SHZ87R57DRE90S4,SHZ87R57DRN63L4,SHZ87R57DRN63M4,SHZ87R57DRN63MS4,SHZ87R57DRN63S4,SHZ87R57DRN71D4,SHZ87R57DRN71M4,SHZ87R57DRN71MS4,SHZ87R57DRN71S4,SHZ87R57DRN80K4,SHZ87R57DRN80M4,SHZ87R57DRN80MK4,SHZ87R57DRN80N4,SHZ87R57DRN80S4,SHZ87R57DRN90L4,SHZ87R57DRN90M4,SHZ87R57DRN90S4,SHZ87R57DRS63L4,SHZ87R57DRS63M4,SHZ87R57DRS63MS4,SHZ87R57DRS63S4,SHZ87R57DRS71D4,SHZ87R57DRS71M4,SHZ87R57DRS71MS4,SHZ87R57DRS71S4,SHZ87R57DRS80K4,SHZ87R57DRS80M4,SHZ87R57DRS80MK4,SHZ87R57DRS80N4,SHZ87R57DRS80S4,SHZ87R57DRS90L4,SHZ87R57DRS90M4,SHZ87R57DRS90S4,SHZ87R57DT63L4,SHZ87R57DT63M4,SHZ87R57DT63MS4,SHZ87R57DT63S4,SHZ87R57DT71D4,SHZ87R57DT71M4,SHZ87R57DT71MS4,SHZ87R57DT71S4,SHZ87R57DT80K4,SHZ87R57DT80M4,SHZ87R57DT80MK4,SHZ87R57DT80N4,SHZ87R57DT80S4,SHZ87R57DT90L4,SHZ87R57DT90M4,SHZ87R57DT90S4,SHZ87R57DV63L4,SHZ87R57DV63M4,SHZ87R57DV63MS4,SHZ87R57DV63S4,SHZ87R57DV71D4,SHZ87R57DV71M4,SHZ87R57DV71MS4,SHZ87R57DV71S4,SHZ87R57DV80K4,SHZ87R57DV80M4,SHZ87R57DV80MK4,SHZ87R57DV80N4,SHZ87R57DV80S4,SHZ87R57DV90L4,SHZ87R57DV90M4,SHZ87R57DV90S4,SHZ87R57DVE63L4,SHZ87R57DVE63M4,SHZ87R57DVE63MS4,SHZ87R57DVE63S4,SHZ87R57DVE71D4,SHZ87R57DVE71M4,SHZ87R57DVE71MS4,SHZ87R57DVE71S4,SHZ87R57DVE80K4,SHZ87R57DVE80M4,SHZ87R57DVE80MK4,SHZ87R57DVE80N4,SHZ87R57DVE80S4,SHZ87R57DVE90L4,SHZ87R57DVE90M4,SHZ87R57DVE90S4,SHZ87RF57-Y0.12KW,SHZ87RF57-Y0.18KW,SHZ87RF57-Y0.25KW,SHZ87RF57-Y0.37KW,SHZ87RF57-Y0.55KW,SHZ87RF57-Y0.75KW,SHZ87RF57-Y1.1KW,SHZ87RF57-Y1.5KW,SHZ87RF57-Y63M4,SHZ87RF57-Y71M4,SHZ87RF57-Y80M4,SHZ87RF57-Y90M4,SHZ87RF57-YEJ0.12KW,SHZ87RF57-YEJ0.18KW,SHZ87RF57-YEJ0.25KW,SHZ87RF57-YEJ0.37KW,SHZ87RF57-YEJ0.55KW,SHZ87RF57-YEJ0.75KW,SHZ87RF57-YEJ1.1KW,SHZ87RF57-YEJ1.5KW,SHZ87RF57-YEJ63M4,SHZ87RF57-YEJ71M4,SHZ87RF57-YEJ80M4,SHZ87RF57-YEJ90S4,SHZ87RF57-YVP0.12KW,SHZ87RF57-YVP0.18KW,SHZ87RF57-YVP0.25KW,SHZ87RF57-YVP0.37KW,SHZ87RF57-YVP0.55KW,SHZ87RF57-YVP0.75KW,SHZ87RF57-YVP1.1KW,SHZ87RF57-YVP1.5KW,SHZ87RF57-YVP63M4,SHZ87RF57-YVP71M4,SHZ87RF57-YVP80M4,SHZ87RF57-YVP90S4,SHZ87RF57-YVPEJ0.12KW,SHZ87RF57-YVPEJ0.18KW,SHZ87RF57-YVPEJ0.25KW,SHZ87RF57-YVPEJ0.37KW,SHZ87RF57-YVPEJ0.55KW,SHZ87RF57-YVPEJ0.75KW,SHZ87RF57-YVPEJ1.1KW,SHZ87RF57-YVPEJ1.5KW,SHZ87RF57-YVPEJ63M4,SHZ87RF57-YVPEJ71M4,SHZ87RF57-YVPEJ80M4,SHZ87RF57-YVPEJ90S4,SAZ87R57DM63L4,SAZ87R57DM63M4,SAZ87R57DM63MS4,SAZ87R57DM63S4,SAZ87R57DM71D4,SAZ87R57DM71M4,SAZ87R57DM71MS4,SAZ87R57DM71S4,SAZ87R57DM80K4,SAZ87R57DM80M4,SAZ87R57DM80MK4,SAZ87R57DM80N4,SAZ87R57DM80S4,SAZ87R57DM90L4,SAZ87R57DM90M4,SAZ87R57DM90S4,SAZ87R57DR63L4,SAZ87R57DR63M4,SAZ87R57DR63MS4,SAZ87R57DR63S4,SAZ87R57DR71D4,SAZ87R57DR71M4,SAZ87R57DR71MS4,SAZ87R57DR71S4,SAZ87R57DR80K4,SAZ87R57DR80M4,SAZ87R57DR80MK4,SAZ87R57DR80N4,SAZ87R57DR80S4,SAZ87R57DR90L4,SAZ87R57DR90M4,SAZ87R57DR90S4,SAZ87R57DRE63L4,SAZ87R57DRE63M4,SAZ87R57DRE63MS4,SAZ87R57DRE63S4,SAZ87R57DRE71D4,SAZ87R57DRE71M4,SAZ87R57DRE71MS4,SAZ87R57DRE71S4,SAZ87R57DRE80K4,SAZ87R57DRE80M4,SAZ87R57DRE80MK4,SAZ87R57DRE80N4,SAZ87R57DRE80S4,SAZ87R57DRE90L4,SAZ87R57DRE90M4,SAZ87R57DRE90S4,SAZ87R57DRN63L4,SAZ87R57DRN63M4,SAZ87R57DRN63MS4,SAZ87R57DRN63S4,SAZ87R57DRN71D4,SAZ87R57DRN71M4,SAZ87R57DRN71MS4,SAZ87R57DRN71S4,SAZ87R57DRN80K4,SAZ87R57DRN80M4,SAZ87R57DRN80MK4,SAZ87R57DRN80N4,SAZ87R57DRN80S4,SAZ87R57DRN90L4,SAZ87R57DRN90M4,SAZ87R57DRN90S4,SAZ87R57DRS63L4,SAZ87R57DRS63M4,SAZ87R57DRS63MS4,SAZ87R57DRS63S4,SAZ87R57DRS71D4,SAZ87R57DRS71M4,SAZ87R57DRS71MS4,SAZ87R57DRS71S4,SAZ87R57DRS80K4,SAZ87R57DRS80M4,SAZ87R57DRS80MK4,SAZ87R57DRS80N4,SAZ87R57DRS80S4,SAZ87R57DRS90L4,SAZ87R57DRS90M4,SAZ87R57DRS90S4,SAZ87R57DT63L4,SAZ87R57DT63M4,SAZ87R57DT63MS4,SAZ87R57DT63S4,SAZ87R57DT71D4,SAZ87R57DT71M4,SAZ87R57DT71MS4,SAZ87R57DT71S4,SAZ87R57DT80K4,SAZ87R57DT80M4,SAZ87R57DT80MK4,SAZ87R57DT80N4,SAZ87R57DT80S4,SAZ87R57DT90L4,SAZ87R57DT90M4,SAZ87R57DT90S4,SAZ87R57DV63L4,SAZ87R57DV63M4,SAZ87R57DV63MS4,SAZ87R57DV63S4,SAZ87R57DV71D4,SAZ87R57DV71M4,SAZ87R57DV71MS4,SAZ87R57DV71S4,SAZ87R57DV80K4,SAZ87R57DV80M4,SAZ87R57DV80MK4,SAZ87R57DV80N4,SAZ87R57DV80S4,SAZ87R57DV90L4,SAZ87R57DV90M4,SAZ87R57DV90S4,SAZ87R57DVE63L4,SAZ87R57DVE63M4,SAZ87R57DVE63MS4,SAZ87R57DVE63S4,SAZ87R57DVE71D4,SAZ87R57DVE71M4,SAZ87R57DVE71MS4,SAZ87R57DVE71S4,SAZ87R57DVE80K4,SAZ87R57DVE80M4,SAZ87R57DVE80MK4,SAZ87R57DVE80N4,SAZ87R57DVE80S4,SAZ87R57DVE90L4,SAZ87R57DVE90M4,SAZ87R57DVE90S4,SAZ87RF57-Y0.12KW,SAZ87RF57-Y0.18KW,SAZ87RF57-Y0.25KW,SAZ87RF57-Y0.37KW,SAZ87RF57-Y0.55KW,SAZ87RF57-Y0.75KW,SAZ87RF57-Y1.1KW,SAZ87RF57-Y1.5KW,SAZ87RF57-Y63M4,SAZ87RF57-Y71M4,SAZ87RF57-Y80M4,SAZ87RF57-Y90M4,SAZ87RF57-YEJ0.12KW,SAZ87RF57-YEJ0.18KW,SAZ87RF57-YEJ0.25KW,SAZ87RF57-YEJ0.37KW,SAZ87RF57-YEJ0.55KW,SAZ87RF57-YEJ0.75KW,SAZ87RF57-YEJ1.1KW,SAZ87RF57-YEJ1.5KW,SAZ87RF57-YEJ63M4,SAZ87RF57-YEJ71M4,SAZ87RF57-YEJ80M4,SAZ87RF57-YEJ90S4,SAZ87RF57-YVP0.12KW,SAZ87RF57-YVP0.18KW,SAZ87RF57-YVP0.25KW,SAZ87RF57-YVP0.37KW,SAZ87RF57-YVP0.55KW,SAZ87RF57-YVP0.75KW,SAZ87RF57-YVP1.1KW,SAZ87RF57-YVP1.5KW,SAZ87RF57-YVP63M4,SAZ87RF57-YVP71M4,SAZ87RF57-YVP80M4,SAZ87RF57-YVP90S4,SAZ87RF57-YVPEJ0.12KW,SAZ87RF57-YVPEJ0.18KW,SAZ87RF57-YVPEJ0.25KW,SAZ87RF57-YVPEJ0.37KW,SAZ87RF57-YVPEJ0.55KW,SAZ87RF57-YVPEJ0.75KW,SAZ87RF57-YVPEJ1.1KW,SAZ87RF57-YVPEJ1.5KW,SAZ87RF57-YVPEJ63M4,SAZ87RF57-YVPEJ71M4,SAZ87RF57-YVPEJ80M4,SAZ87RF57-YVPEJ90S4。
S88R58減速電機生產廠家展示：看廠請聯系微信13827261050，獲取位置，需提前一天預約http://www.socclo.com/product/list-sxiliejiansuji-cn.html
推薦型號：S88減速機
關鍵詞:G系列減速機一體式_S系列斜齒輪蝸輪蝸桿減速機_S系列減速機_減速機配司服電機連接_S型減速機_司服電機減速機_S系列減速機器_司服減速機
S系列減速機型號：S38減速機,S48減速機,S58減速機,S68減速機,S78減速機,S88減速機,S98齒輪減速馬達
S系列自鎖減速機可配變頻電機，剎車電機，防爆電機，伺服電機，交流電機，直流電機，三相電機，單相電機 0.12KW-22KW之間
如需工程師幫選型，請加微信13827261050，留言告知工程師參數要求
