F68R38減速機詳細信息

prevnext

F68R38減速機

訂購熱線：13360667204

詳細信息

F68R38減速機電機功率：F68R38Y0.12KW減速機,F68R38Y0.18KW減速機,F68R38Y0.25KW減速機,F68R38Y0.37KW減速機,F68R38Y0.55KW減速機（可配變頻電機，剎車電機，防爆電機，伺服電機，交流電機，直流電機，三相電機，單相電機）。

F68R38減速機配0.12KW電機參數

型號	減速比	功率	轉數	扭矩	重量	力矩	安全系數
F68R38-Y0.12KW	1429	0.12KW	0.97r/min	960N.m	69kg	7070N	0.85
F68R38-Y0.12KW	1271	0.12KW	1.10r/min	860N.m	69kg	9840N	0.95
F68R38-Y0.12KW	1102	0.12KW	1.20r/min	725N.m	69kg	11100N	1.15
F68R38-Y0.12KW	970	0.12KW	1.40r/min	635N.m	69kg	11700N	1.30
F68R38-Y0.12KW	858	0.12KW	1.60r/min	560N.m	69kg	12100N	1.45
F68R38-Y0.12KW	755	0.12KW	1.80r/min	490N.m	69kg	12400N	1.65
F68R38-Y0.12KW	641	0.12KW	2.20r/min	415N.m	69kg	12700N	1.95
F68R38-Y0.12KW	572	0.12KW	2.40r/min	390N.m	69kg	12800N	2.10
F68R38-Y0.12KW	509	0.12KW	2.70r/min	330N.m	69kg	13000N	2.50
F68R38-Y0.12KW	437	0.12KW	3.20r/min	285N.m	69kg	13000N	2.80

F68R38減速機配0.18KW電機參數

型號	減速比	功率	轉數	扭矩	重量	力矩	安全系數
F68R38-Y0.18KW	858	0.18KW	1.50r/min	940N.m	69.5kg	8660N	0.85
F68R38-Y0.18KW	755	0.18KW	1.80r/min	820N.m	69.5kg	10200N	1.00
F68R38-Y0.18KW	641	0.18KW	2.10r/min	700N.m	69.5kg	11200N	1.15
F68R38-Y0.18KW	572	0.18KW	2.30r/min	645N.m	69.5kg	11600N	1.25
F68R38-Y0.18KW	509	0.18KW	2.60r/min	555N.m	69.5kg	12100N	1.45
F68R38-Y0.18KW	437	0.18KW	3.00r/min	480N.m	69.5kg	12500N	1.70
F68R38-Y0.18KW	384	0.18KW	3.40r/min	430N.m	69.5kg	12700N	1.90
F68R38-Y0.18KW	500	0.18KW	2.60r/min	575N.m	69.5kg	12000N	1.40
F68R38-Y0.18KW	454	0.18KW	2.90r/min	525N.m	69.5kg	12300N	1.55
F68R38-Y0.18KW	392	0.18KW	3.40r/min	450N.m	69.5kg	12600N	1.80
F68R38-Y0.18KW	333	0.18KW	4.00r/min	380N.m	69.5kg	12900N	2.20
F68R38-Y0.18KW	297	0.18KW	4.40r/min	335N.m	69.5kg	13000N	2.40
F68R38-Y0.18KW	261	0.18KW	5.10r/min	295N.m	69.5kg	13000N	2.80
F68R38-Y0.18KW	238	0.18KW	5.60r/min	260N.m	69.5kg	13000N	3.10
F68R38-Y0.18KW	200	0.18KW	6.60r/min	215N.m	69.5kg	13000N	3.70

F68R38減速機配0.25KW電機參數

型號	減速比	功率	轉數	扭矩	重量	力矩	安全系數
F68R38-Y0.25KW	572	0.25KW	2.30r/min	930N.m	73.5kg	9150N	0.90
F68R38-Y0.25KW	509	0.25KW	2.60r/min	810N.m	73.5kg	10400N	1.00
F68R38-Y0.25KW	437	0.25KW	3.00r/min	700N.m	73.5kg	11200N	1.15
F68R38-Y0.25KW	500	0.25KW	2.60r/min	830N.m	73.5kg	10200N	1.00
F68R38-Y0.25KW	454	0.25KW	2.90r/min	755N.m	73.5kg	10800N	1.10
F68R38-Y0.25KW	392	0.25KW	3.30r/min	650N.m	73.5kg	11600N	1.25
F68R38-Y0.25KW	333	0.25KW	3.90r/min	550N.m	73.5kg	12200N	1.50
F68R38-Y0.25KW	297	0.25KW	4.40r/min	485N.m	73.5kg	12500N	1.70
F68R38-Y0.25KW	261	0.25KW	5.00r/min	425N.m	73.5kg	12700N	1.90
F68R38-Y0.25KW	238	0.25KW	5.50r/min	385N.m	73.5kg	12900N	2.10

F68R38減速機配0.37KW電機參數

型號	減速比	功率	轉數	扭矩	重量	力矩	安全系數
F68R38-Y0.37KW	384	0.37KW	3.60r/min	880N.m	74kg	9670N	0.95
F68R38-Y0.37KW	338	0.37KW	4.10r/min	785N.m	74kg	10600N	1.05
F68R38-Y0.37KW	305	0.37KW	4.50r/min	700N.m	74kg	11200N	1.15
F68R38-Y0.37KW	257	0.37KW	5.40r/min	590N.m	74kg	11900N	1.40
F68R38-Y0.37KW	231	0.37KW	6.00r/min	520N.m	74kg	12300N	1.55

F68R38減速機配0.55KW電機參數

型號	減速比	功率	轉數	扭矩	重量	力矩	安全系數
F68R38-Y0.55KW	257	0.55KW	5.40r/min	890N.m	78.5kg	9610N	0.90
F68R38-Y0.55KW	231	0.55KW	6.00r/min	790N.m	78.5kg	10500N	1.05
F68R38-Y0.55KW	205	0.55KW	6.70r/min	705N.m	78.5kg	11200N	1.15
F68R38-Y0.55KW	175	0.55KW	7.90r/min	600N.m	78.5kg	11900N	1.35

F68R38減速器減速比：175比減速器,200比減速器,205比齒輪減速馬達,231比減速器,238比減速器,257比減速器,261比減速器,297比減速器,305比減速器,333比減速器,338比減速器,384比減速器,392比減速器,437比減速器,454比減速器,500比減速器,509比減速器,572比減速器,641比減速器,755比減速器,858比減速器,970比減速器,1102比減速器,1271比減速器,1429比減速器。

F68R38減速機電機安裝尺寸：輸出軸Φ40+鍵3（可定做），高343*寬212*長421（帶輸出軸）

F68R38減速電機輸出轉數：0.97轉減速電機,1.1轉減速電機,1.2轉減速電機,1.4轉減速電機,1.5轉減速電機,1.6轉減速電機,1.8轉平行軸斜齒輪減速機,2.1轉減速電機,2.2轉減速電機,2.3轉減速電機,2.4轉減速電機,2.6轉減速電機,2.7轉減速電機,2.9轉減速電機,3轉減速電機,3.2轉減速電機,3.3轉減速電機,3.4轉減速電機,3.6轉減速電機,3.9轉減速電機,4轉減速電機,4.1轉減速電機,4.4轉減速電機,4.5轉減速電機,5轉減速電機,5.1轉減速電機,5.4轉減速電機,5.5轉減速電機,5.6轉減速電機,6轉減速電機,6.6轉減速電機,6.7轉減速電機,7.9轉減速電機。

F68R38減速箱電機輸出扭矩：215N.m減速箱,260N.m減速箱,285N.m減速箱,295N.m減速箱,330N.m減速箱,335N.m減速箱,380N.m減速箱,385N.m減速箱,390N.m減速箱,415N.m減速箱,425N.m減速箱,430N.m減速箱,450N.m減速箱,480N.m減速箱,485N.m減速箱,490N.m減速箱,520N.m減速箱,525N.m減速箱,550N.m減速箱,555N.m減速箱,560N.m減速箱,575N.m減速箱,590N.m減速箱,600N.m減速箱,635N.m減速箱,645N.m減速箱,650N.m減速箱,700N.m減速箱,705N.m減速箱,725N.m減速箱,755N.m減速箱,785N.m減速箱,790N.m減速箱,810N.m減速箱,820N.m減速箱,830N.m減速箱,860N.m減速箱,880N.m減速箱,890N.m減速箱,930N.m減速箱,940N.m減速箱,960N.m減速箱。

F68R38減速機電機各種輸出實物圖：

F68R38減速馬達型號：

FHZ67R37DM63L4,FHZ67R37DM63M4,FHZ67R37DM63MS4,FHZ67R37DM63S4,FHZ67R37DM71D4,FHZ67R37DM71M4,FHZ67R37DM71MS4,FHZ67R37DM71S4,FHZ67R37DM80K4,FHZ67R37DM80M4,FHZ67R37DM80MK4,FHZ67R37DM80N4,FHZ67R37DM80S4,FHZ67R37DR63L4,FHZ67R37DR63M4,FHZ67R37DR63MS4,FHZ67R37DR63S4,FHZ67R37DR71D4,FHZ67R37DR71M4,FHZ67R37DR71MS4,FHZ67R37DR71S4,FHZ67R37DR80K4,FHZ67R37DR80M4,FHZ67R37DR80MK4,FHZ67R37DR80N4,FHZ67R37DR80S4,FHZ67R37DRE63L4,FHZ67R37DRE63M4,FHZ67R37DRE63MS4,FHZ67R37DRE63S4,FHZ67R37DRE71D4,FHZ67R37DRE71M4,FHZ67R37DRE71MS4,FHZ67R37DRE71S4,FHZ67R37DRE80K4,FHZ67R37DRE80M4,FHZ67R37DRE80MK4,FHZ67R37DRE80N4,FHZ67R37DRE80S4,FHZ67R37DRN63L4,FHZ67R37DRN63M4,FHZ67R37DRN63MS4,FHZ67R37DRN63S4,FHZ67R37DRN71D4,FHZ67R37DRN71M4,FHZ67R37DRN71MS4,FHZ67R37DRN71S4,FHZ67R37DRN80K4,FHZ67R37DRN80M4,FHZ67R37DRN80MK4,FHZ67R37DRN80N4,FHZ67R37DRN80S4,FHZ67R37DRS63L4,FHZ67R37DRS63M4,FHZ67R37DRS63MS4,FHZ67R37DRS63S4,FHZ67R37DRS71D4,FHZ67R37DRS71M4,FHZ67R37DRS71MS4,FHZ67R37DRS71S4,FHZ67R37DRS80K4,FHZ67R37DRS80M4,FHZ67R37DRS80MK4,FHZ67R37DRS80N4,FHZ67R37DRS80S4,FHZ67R37DT63L4,FHZ67R37DT63M4,FHZ67R37DT63MS4,FHZ67R37DT63S4,FHZ67R37DT71D4,FHZ67R37DT71M4,FHZ67R37DT71MS4,FHZ67R37DT71S4,FHZ67R37DT80K4,FHZ67R37DT80M4,FHZ67R37DT80MK4,FHZ67R37DT80N4,FHZ67R37DT80S4,FHZ67R37DV63L4,FHZ67R37DV63M4,FHZ67R37DV63MS4,FHZ67R37DV63S4,FHZ67R37DV71D4,FHZ67R37DV71M4,FHZ67R37DV71MS4,FHZ67R37DV71S4,FHZ67R37DV80K4,FHZ67R37DV80M4,FHZ67R37DV80MK4,FHZ67R37DV80N4,FHZ67R37DV80S4,FHZ67R37DVE63L4,FHZ67R37DVE63M4,FHZ67R37DVE63MS4,FHZ67R37DVE63S4,FHZ67R37DVE71D4,FHZ67R37DVE71M4,FHZ67R37DVE71MS4,FHZ67R37DVE71S4,FHZ67R37DVE80K4,FHZ67R37DVE80M4,FHZ67R37DVE80MK4,FHZ67R37DVE80N4,FHZ67R37DVE80S4,FHZ67RF37-Y0.12KW,FHZ67RF37-Y0.18KW,FHZ67RF37-Y0.25KW,FHZ67RF37-Y0.37KW,FHZ67RF37-Y0.55KW,FHZ67RF37-Y0.75KW,FHZ67RF37-Y63M4,FHZ67RF37-Y71M4,FHZ67RF37-Y80M4,FHZ67RF37-YEJ0.12KW,FHZ67RF37-YEJ0.18KW,FHZ67RF37-YEJ0.25KW,FHZ67RF37-YEJ0.37KW,FHZ67RF37-YEJ0.55KW,FHZ67RF37-YEJ0.75KW,FHZ67RF37-YEJ63M4,FHZ67RF37-YEJ71M4,FHZ67RF37-YEJ80M4,FHZ67RF37-YVP0.12KW,FHZ67RF37-YVP0.18KW,FHZ67RF37-YVP0.25KW,FHZ67RF37-YVP0.37KW,FHZ67RF37-YVP0.55KW,FHZ67RF37-YVP0.75KW,FHZ67RF37-YVP63M4,FHZ67RF37-YVP71M4,FHZ67RF37-YVP80M4,FHZ67RF37-YVPEJ0.12KW,FHZ67RF37-YVPEJ0.18KW,FHZ67RF37-YVPEJ0.25KW,FHZ67RF37-YVPEJ0.37KW,FHZ67RF37-YVPEJ0.55KW,FHZ67RF37-YVPEJ0.75KW,FHZ67RF37-YVPEJ63M4,FHZ67RF37-YVPEJ71M4,FHZ67RF37-YVPEJ80M4,FVZ67R37DM63L4,FVZ67R37DM63M4,FVZ67R37DM63MS4,FVZ67R37DM63S4,FVZ67R37DM71D4,FVZ67R37DM71M4,FVZ67R37DM71MS4,FVZ67R37DM71S4,FVZ67R37DM80K4,FVZ67R37DM80M4,FVZ67R37DM80MK4,FVZ67R37DM80N4,FVZ67R37DM80S4,FVZ67R37DR63L4,FVZ67R37DR63M4,FVZ67R37DR63MS4,FVZ67R37DR63S4,FVZ67R37DR71D4,FVZ67R37DR71M4,FVZ67R37DR71MS4,FVZ67R37DR71S4,FVZ67R37DR80K4,FVZ67R37DR80M4,FVZ67R37DR80MK4,FVZ67R37DR80N4,FVZ67R37DR80S4,FVZ67R37DRE63L4,FVZ67R37DRE63M4,FVZ67R37DRE63MS4,FVZ67R37DRE63S4,FVZ67R37DRE71D4,FVZ67R37DRE71M4,FVZ67R37DRE71MS4,FVZ67R37DRE71S4,FVZ67R37DRE80K4,FVZ67R37DRE80M4,FVZ67R37DRE80MK4,FVZ67R37DRE80N4,FVZ67R37DRE80S4,FVZ67R37DRN63L4,FVZ67R37DRN63M4,FVZ67R37DRN63MS4,FVZ67R37DRN63S4,FVZ67R37DRN71D4,FVZ67R37DRN71M4,FVZ67R37DRN71MS4,FVZ67R37DRN71S4,FVZ67R37DRN80K4,FVZ67R37DRN80M4,FVZ67R37DRN80MK4,FVZ67R37DRN80N4,FVZ67R37DRN80S4,FVZ67R37DRS63L4,FVZ67R37DRS63M4,FVZ67R37DRS63MS4,FVZ67R37DRS63S4,FVZ67R37DRS71D4,FVZ67R37DRS71M4,FVZ67R37DRS71MS4,FVZ67R37DRS71S4,FVZ67R37DRS80K4,FVZ67R37DRS80M4,FVZ67R37DRS80MK4,FVZ67R37DRS80N4,FVZ67R37DRS80S4,FVZ67R37DT63L4,FVZ67R37DT63M4,FVZ67R37DT63MS4,FVZ67R37DT63S4,FVZ67R37DT71D4,FVZ67R37DT71M4,FVZ67R37DT71MS4,FVZ67R37DT71S4,FVZ67R37DT80K4,FVZ67R37DT80M4,FVZ67R37DT80MK4,FVZ67R37DT80N4,FVZ67R37DT80S4,FVZ67R37DV63L4,FVZ67R37DV63M4,FVZ67R37DV63MS4,FVZ67R37DV63S4,FVZ67R37DV71D4,FVZ67R37DV71M4,FVZ67R37DV71MS4,FVZ67R37DV71S4,FVZ67R37DV80K4,FVZ67R37DV80M4,FVZ67R37DV80MK4,FVZ67R37DV80N4,FVZ67R37DV80S4,FVZ67R37DVE63L4,FVZ67R37DVE63M4,FVZ67R37DVE63MS4,FVZ67R37DVE63S4,FVZ67R37DVE71D4,FVZ67R37DVE71M4,FVZ67R37DVE71MS4,FVZ67R37DVE71S4,FVZ67R37DVE80K4,FVZ67R37DVE80M4,FVZ67R37DVE80MK4,FVZ67R37DVE80N4,FVZ67R37DVE80S4,FVZ67RF37-Y0.12KW,FVZ67RF37-Y0.18KW,FVZ67RF37-Y0.25KW,FVZ67RF37-Y0.37KW,FVZ67RF37-Y0.55KW,FVZ67RF37-Y0.75KW,FVZ67RF37-Y63M4,FVZ67RF37-Y71M4,FVZ67RF37-Y80M4,FVZ67RF37-YEJ0.12KW,FVZ67RF37-YEJ0.18KW,FVZ67RF37-YEJ0.25KW,FVZ67RF37-YEJ0.37KW,FVZ67RF37-YEJ0.55KW,FVZ67RF37-YEJ0.75KW,FVZ67RF37-YEJ63M4,FVZ67RF37-YEJ71M4,FVZ67RF37-YEJ80M4,FVZ67RF37-YVP0.12KW,FVZ67RF37-YVP0.18KW,FVZ67RF37-YVP0.25KW,FVZ67RF37-YVP0.37KW,FVZ67RF37-YVP0.55KW,FVZ67RF37-YVP0.75KW,FVZ67RF37-YVP63M4,FVZ67RF37-YVP71M4,FVZ67RF37-YVP80M4,FVZ67RF37-YVPEJ0.12KW,FVZ67RF37-YVPEJ0.18KW,FVZ67RF37-YVPEJ0.25KW,FVZ67RF37-YVPEJ0.37KW,FVZ67RF37-YVPEJ0.55KW,FVZ67RF37-YVPEJ0.75KW,FVZ67RF37-YVPEJ63M4,FVZ67RF37-YVPEJ71M4,FVZ67RF37-YVPEJ80M4,FAZ67R37DM63L4,FAZ67R37DM63M4,FAZ67R37DM63MS4,FAZ67R37DM63S4,FAZ67R37DM71D4,FAZ67R37DM71M4,FAZ67R37DM71MS4,FAZ67R37DM71S4,FAZ67R37DM80K4,FAZ67R37DM80M4,FAZ67R37DM80MK4,FAZ67R37DM80N4,FAZ67R37DM80S4,FAZ67R37DR63L4,FAZ67R37DR63M4,FAZ67R37DR63MS4,FAZ67R37DR63S4,FAZ67R37DR71D4,FAZ67R37DR71M4,FAZ67R37DR71MS4,FAZ67R37DR71S4,FAZ67R37DR80K4,FAZ67R37DR80M4,FAZ67R37DR80MK4,FAZ67R37DR80N4,FAZ67R37DR80S4,FAZ67R37DRE63L4,FAZ67R37DRE63M4,FAZ67R37DRE63MS4,FAZ67R37DRE63S4,FAZ67R37DRE71D4,FAZ67R37DRE71M4,FAZ67R37DRE71MS4,FAZ67R37DRE71S4,FAZ67R37DRE80K4,FAZ67R37DRE80M4,FAZ67R37DRE80MK4,FAZ67R37DRE80N4,FAZ67R37DRE80S4,FAZ67R37DRN63L4,FAZ67R37DRN63M4,FAZ67R37DRN63MS4,FAZ67R37DRN63S4,FAZ67R37DRN71D4,FAZ67R37DRN71M4,FAZ67R37DRN71MS4,FAZ67R37DRN71S4,FAZ67R37DRN80K4,FAZ67R37DRN80M4,FAZ67R37DRN80MK4,FAZ67R37DRN80N4,FAZ67R37DRN80S4,FAZ67R37DRS63L4,FAZ67R37DRS63M4,FAZ67R37DRS63MS4,FAZ67R37DRS63S4,FAZ67R37DRS71D4,FAZ67R37DRS71M4,FAZ67R37DRS71MS4,FAZ67R37DRS71S4,FAZ67R37DRS80K4,FAZ67R37DRS80M4,FAZ67R37DRS80MK4,FAZ67R37DRS80N4,FAZ67R37DRS80S4,FAZ67R37DT63L4,FAZ67R37DT63M4,FAZ67R37DT63MS4,FAZ67R37DT63S4,FAZ67R37DT71D4,FAZ67R37DT71M4,FAZ67R37DT71MS4,FAZ67R37DT71S4,FAZ67R37DT80K4,FAZ67R37DT80M4,FAZ67R37DT80MK4,FAZ67R37DT80N4,FAZ67R37DT80S4,FAZ67R37DV63L4,FAZ67R37DV63M4,FAZ67R37DV63MS4,FAZ67R37DV63S4,FAZ67R37DV71D4,FAZ67R37DV71M4,FAZ67R37DV71MS4,FAZ67R37DV71S4,FAZ67R37DV80K4,FAZ67R37DV80M4,FAZ67R37DV80MK4,FAZ67R37DV80N4,FAZ67R37DV80S4,FAZ67R37DVE63L4,FAZ67R37DVE63M4,FAZ67R37DVE63MS4,FAZ67R37DVE63S4,FAZ67R37DVE71D4,FAZ67R37DVE71M4,FAZ67R37DVE71MS4,FAZ67R37DVE71S4,FAZ67R37DVE80K4,FAZ67R37DVE80M4,FAZ67R37DVE80MK4,FAZ67R37DVE80N4,FAZ67R37DVE80S4,FAZ67RF37-Y0.12KW,FAZ67RF37-Y0.18KW,FAZ67RF37-Y0.25KW,FAZ67RF37-Y0.37KW,FAZ67RF37-Y0.55KW,FAZ67RF37-Y0.75KW,FAZ67RF37-Y63M4,FAZ67RF37-Y71M4,FAZ67RF37-Y80M4,FAZ67RF37-YEJ0.12KW,FAZ67RF37-YEJ0.18KW,FAZ67RF37-YEJ0.25KW,FAZ67RF37-YEJ0.37KW,FAZ67RF37-YEJ0.55KW,FAZ67RF37-YEJ0.75KW,FAZ67RF37-YEJ63M4,FAZ67RF37-YEJ71M4,FAZ67RF37-YEJ80M4,FAZ67RF37-YVP0.12KW,FAZ67RF37-YVP0.18KW,FAZ67RF37-YVP0.25KW,FAZ67RF37-YVP0.37KW,FAZ67RF37-YVP0.55KW,FAZ67RF37-YVP0.75KW,FAZ67RF37-YVP63M4,FAZ67RF37-YVP71M4,FAZ67RF37-YVP80M4,FAZ67RF37-YVPEJ0.12KW,FAZ67RF37-YVPEJ0.18KW,FAZ67RF37-YVPEJ0.25KW,FAZ67RF37-YVPEJ0.37KW,FAZ67RF37-YVPEJ0.55KW,FAZ67RF37-YVPEJ0.75KW,FAZ67RF37-YVPEJ63M4,FAZ67RF37-YVPEJ71M4,FAZ67RF37-YVPEJ80M4。
